Sealed Subminiature Micro Switch With Inner Resistor G3

Sealed Subminiature Micro Switch With Inner Resistor G3

The Sealed Subminiature Micro Switch Without Inner Resistor G3 is a compact yet robust switch designed for various electronic applications.

Due to its small size, it is very suitable for small spaces and has reliable performance. Since there is no internal resistance, it can be flexibly integrated into the circuit without worrying about impedance. This is the best selling product series launched by China micro switch manufacturers after years of optimization

  • ContactResistance (Initiative) 100mΩ Max.(without wire type)
  • Insulation Resistance (at 500VDC) 100mΩ Min.
  • Vibration Durability 10-55Hz,move 0.75mm(p-p)
  • Dielectric Strength 500VAC(50-60Hz)
  • Operating Temperature -40℃~+85℃
  • Operating Humidity 85%RH Max.
Contact us Download
product details
product description

Features

Sealed Submini Micro Switch G3, Sealed design, no inner resistor, compact size for tight spaces, versatile integration into electronic circuits, reliable performance across industries like automotive, consumer electronics, and industrial control.

This micro switch is a sealed subminiature micro switch with good sealing performance. It can withstand harsh environments and is very suitable for industrial and automotive use. For example, the detection system of the car door lock switch uses this sealed switch. In addition, the sealed mini micro switch is also a common switch model for car door lock applications.
Sealed Subminiature Micro Switch With Inner Resistor G303R--9qe

Parameters

Rating 0.1A,125/250VAC;3A/12VDC;0.1A/48VDC;μ1E5
Operating Frequency Electrical 0.1A,120 cycles/min 3A,10~30 cycles/min
Mechanical 120 cycles/min
Contact Resistance (Initiative) 100mΩ Max.(without wire type)
Insulation Resistance (at 500VDC) 100MΩ Min.
Vbration Durability 10~55Hz,move 0.75mm(p-p)
Dielectric Strength 500VAC(50~60Hz)
Operating Temperature -40℃~+85℃
Operating Humidity 85%RH Max
Service Life Electrical Min.100,000 cycles (Depend on part NO.)
Mechanical Min.500,000 cycles

Application

The Sealed Subminiature Micro Switch Without Inner Resistor G3 is widely applied across industries. In automotive systems, it controls various functions like lights and wipers. In consumer electronics, it manages power and mode selection in devices like remote controls. Additionally, it's utilized in industrial control panels for precise equipment operation.If you want to know more about sealed micro switches, please go to the Unionwell waterproof micro switch page for more details!

Dimensions

Sealed Subminiature Micro Switch Without Inner Resistor5k0k

G303-130E00B51J-FL70U

Sealed Subminiature Micro Switch Without Inner Resistor63qc
Sealed Subminiature Micro Switch Without Inner Resistor4zt0

G303-130F00C30H-GFU

Sealed Subminiature Micro Switch Without Inner Resistor3nxf
Sealed Subminiature Micro Switch Without Inner Resistor24rs

G303-130E37B1-FL120U

Sealed Subminiature Micro Switch Without Inner Resistor1nfg
